Vinnant ACARS/VDL/Airband Outdoor Antenna

An affordable omnidirectional antenna for outdoor reception of ACARS, VDL, and other airband aviation (118-137mhz) signals from overhead/nearby aircraft and towers.

An outdoor antenna will always perform better than an indoor antenna, because outdoor antennas have:

• better line-of-sight
• better reception without filtration from building materials
• less localized interference

This outdoor antenna will not break the bank considering it is high quality and is tuned for ACARS, VDL, and general airband reception in the 118-137mhz frequencies.

Specifications

• Length 60cm (74cm w/ holder)
• Width 70cm
• Type N female connector
• 2.15 dBi gain on receive
• 25 to 50 mm pole mounting diameter
• Tuning 126mhz / Non-tunable
• Bandwidth 6-9mhz
• Enclosure black fiberglass radome (UV stable)
• Radials are stainless steel
• DC ground for static protection
• SWR 1.2:1 or better
• Impedance 50 ohm
