Vinnant ADS-B 1090mhz Indoor Antenna

An affordable medium-performance omni-directional antenna for indoor reception of ADS-B aviation signals from overhead/nearby aircraft.

An outdoor antenna will always perform better than an indoor antenna, because outdoor antennas have:

• better line-of-sight
• better reception without filtration from building materials
• less localized interference

However, sometimes you just can't set up an outdoor antenna because you:

• live in an HOA condo, townhouse, or home that has rules against
• not yet ready to mount/drill/etc outside
• are just developing/testing something and need it simple

This indoor antenna design won't break the bank, but it'll still give you the ADS-B reception you are hoping for (considering it is indoors).

Specifications

• 5/8th wave
• 3 robust radials
• Type N connector
• 3 dB gain on receive
• 55mm mounting diameter
• Type Z5 holder (~30cm length)
• non-tunable
• aluminum polycarbonate
• DC ground for static protection
• SWR 1.5:1 or better
• Impedance 50 ohm
• Temperature range -30C to +70C
